Laser Amorphization of a Crystalline Phase in the Bulk of a Thermally Stable Lithium Aluminosilicate Glass-Ceramic

A. S. Naumov; Наумов А. С.; S. V. Lotarev; Лотарев С. В.; A. S. Lipatiev; Липатьев А. С.; G. Yu. Shakhgildyan; Шахгильдян Г. Ю.; S. S. Fedotov; Федотов С. С.; E. V. Lopatina; Лопатина Е. В.; I. A. Karateev; Каратеев И. А.; V. N. Sigaev; Сигаев В. Н.

doi:10.31857/S0002337X23040085

Laser Amorphization of a Crystalline Phase in the Bulk of a Thermally Stable Lithium Aluminosilicate Glass-Ceramic

Authors: Naumov A.S.¹, Lotarev S.V.¹, Lipatiev A.S.¹, Shakhgildyan G.Y.¹, Fedotov S.S.¹, Lopatina E.V.¹, Karateev I.A.², Sigaev V.N.¹
Affiliations:
1. Mendeleev University of Chemical Technology, 125047, Moscow, Russia
2. Kurchatov Institute National Research Center, 123098, Moscow, Russia
Issue: Vol 59, No 4 (2023)
Pages: 419-424
Section: Articles
URL: https://rjonco.com/0002-337X/article/view/668276
DOI: https://doi.org/10.31857/S0002337X23040085
EDN: https://elibrary.ru/VUCCNI
ID: 668276

Cite item

Full Text

Open Access
Restricted Access

Access granted
Restricted Access

Subscription Access

Abstract
About the authors
References
Supplementary files
Statistics

Abstract

This paper presents results of femtosecond laser micromachining of a transparent glass-ceramic in the Li2O–Al2O3–SiO2 system with a near-zero linear thermal expansion coefficient in the thermal and athermal regimes. Electron microscopy and electron diffraction data confirm complete amorphization of nanocrystals of β-eucryptite-like solid solutions under the effect of laser pulses. Using quantitative phase microscopy, we have evaluated refractive index changes in individual laser-written tracks. In the athermal regime at a pulse repetition rate of 10 kHz, complete glass-ceramic amorphization leads to a decrease in the refractive index of the material (Δn = −0.0035) in the laser treatment region, which opens up the possibility of using direct laser writing of channel waveguides in a thermally stable glass-ceramic matrix.

Keywords

lithium aluminosilicate glass-ceramic, linear thermal expansion coefficient, femtosecond laser, laser amorphization

References

Low Thermal Expansion Glass Ceramics / Eds. Bach H., Krause D. Berlin, Heidelberg: Springer, 2005. P. 121–235. https://doi.org/10.1007/3-540-28245-9_3
Hartmann P., Jedamzik R., Carré A., Krieg J., Westerhoff T. Glass ceramic ZERODUR®: Even Closer to Zero Thermal Expansion: a Review. Part 1 // JATIS. 2021. V. 7. № 2. P. 020901. https://doi.org/10.1117/1.JATIS.7.2.020901
Mitra I. ZERODUR: a Glass-Ceramic Material Enabling Optical Technologies // Opt. Mater. Express. 2022. V. 12. № 9. P. 3563–3576. https://doi.org/10.1364/OME.460265
Venkateswaran C., Sreemoolanadhan H., Vaish R. Lithium Aluminosilicate (LAS) Glass-Ceramics: a Review of Recent Progress // Int. Mater. Rev. 2022. V. 67. № 6. P. 620–657. https://doi.org/10.1080/09506608.2021.1994108
Passaro V.M., Cuccovillo A., Vaiani L., De Carlo M., Campanella C.E. Gyroscope Technology and Applications: A Review in the Industrial Perspective // Sensors. 2017. V. 17 № 1. P. 2284. https://doi.org/10.3390/s17102284
Tan D., Zhang B., Qiu J. Ultrafast Laser Direct Writing in Glass: Thermal Accumulation Engineering and Applications // Laser Photonics Rev. 2021. V. 15. № 9. P. 2000455. https://doi.org/10.1002/lpor.202000455
Bhardwaj V.R., Simova E., Corkum P.B., Rayner D.M. Femtosecond Laser-Induced Refractive Index Modification in Multicomponent Glasses // J. Appl. Phys. 2005. V. 97. № 8. P. 083102. https://doi.org/10.1063/1.1876578
Lipatiev A., Fedotov S., Lotarev S., Naumov A., Lipateva T., Savinkov V., Shakhgildyan G., Sigaev V. Direct Laser Writing of Depressed-Cladding Waveguides in Extremely Low Expansion Lithium Aluminosilicate Glass-Ceramics // Opt. Laser Technol. 2021. V. 138. P. 106846. https://doi.org/10.1016/j.optlastec.2020.106846
Guan J. Femtosecond-Laser-Written Integrated Photonics in Bulk Glass-Ceramics Zerodur // Ceram. Int. 2021. V. 47. № 7. P. 10189–10192. https://doi.org/10.1016/j.ceramint.2020.12.099
Наумов А.С., Лотарев С.В., Липатьев А.С., Федотов С.С., Савинков В.И., Сигаев В.Н. Способ лазерной записи интегральных волноводов: Пат. РФ № 2781465 С1. 2022.
Lotarev S.V., Lipatiev A.S., Lipateva T.O., Fedotov S.S., Naumov A.S., Moiseev I.A., Sigaev V.N. Ultrafast-Laser Vitrification of Laser-Written Crystalline Tracks in Oxide Glasses // J. Non-Cryst. Solids. 2019. V. 516. P. 1–8. https://doi.org/10.1016/j.jnoncrysol.2019.04.027
Сигаев В.Н., Савинков В.И., Шахгильдян Г.Ю., Наумов А.С., Лотарев С.В., Клименко Н.Н., Голубев Н.В., Пресняков М.Ю. О возможности прецизионного управления температурным коэффициентом линейного расширения прозрачных литиево-алюмосиликатных ситаллов вблизи нулевых значений // Стекло и керамика. 2019. № 12. С. 11–16.
Сигаев В.Н., Липатьев А.С., Федотов С.C., Лотарев С.В., Шахгильдян Г.Ю., Наумов А.С., Савинков В.И. Фемтосекундное лазерное модифицирование прозрачного литиево-алюмосиликатного ситалла и исходного стекла, содержащего сурьму // Стекло и керамика. 2019. № 10. С. 9–13.
Choudhury D., Macdonald J.R., Kar A.K. Ultrafast Laser Inscription: Perspectives on Future Integrated Applications // Laser Photonics Rev. 2014. V. 8. № 6. P. 827–846. https://doi.org/10.1002/lpor.201300195
Alekseeva I., Dymshits O., Ermakov V., Zhilin A., Petrov V., Tsenter M. Raman Spectroscopy Quantifying the Composition of Stuffed β-Quartz Derivative Phases in Lithium Aluminosilicate Glass-Ceramics // J. Non-Cryst. Solids. 2008. V. 354. № 45–46. P. 4932–4939. https://doi.org/10.1016/j.jnoncrysol.2008.07.016
Eaton S.M., Zhang H., Herman P.R., Yoshino F., Shah L., Bovatsek J., Arai A.Y. Heat Accumulation Effects in Femtosecond Laser-Written Waveguides with Variable Repetition Rate // Opt. Express. 2018. V. 13. P. 4708–4716. https://doi.org/10.1364/OPEX.13.004708
