The effect of nitriding temperature on the formation of surface layers of vanadium-titanium alloy Ti–6Al–4V

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription Access

Abstract

In this work, using the methods of atomic force microscopy (AFM), X-ray photoelectron spectroscopy (XPS) and X-ray diffraction analysis (XRD), the features of the formation of surface morphology, chemical and phase composition of near-surface and surface layers during ion-plasma processing of the Ti–6Al–4V (VT6) alloy in a glow discharge plasma of N+ ions were studied. depending on the temperature of the samples. It has been shown that increasing the sample temperature from 300 to 700°С during processing leads to an increase in the surface roughness parameters Ra and Rz, due to the formation of titanium nitrides Ti2N and TiN on the surface of the alloy. Based on the conducted research, it is assumed that the formation of thin near-surface layers (~20 nm) during treatment in nitrogen plasma without heating and with heating to 300°С is determined by the oxidation processes of alloy components, and when processing with heating to 500 and 700°С by nitrogen diffusion processes.

Full Text

Restricted Access

About the authors

V. L. Vorobyev

Udmurt Federal Research Center, Ural Branch of the Russian Academy of Sciences

Author for correspondence.
Email: Vasily_L.84@udman.ru
Russian Federation, Izhevsk

V. S. Gladysheva

Udmurt Federal Research Center, Ural Branch of the Russian Academy of Sciences

Email: Vasily_L.84@udman.ru
Russian Federation, Izhevsk

S. G. Bystrov

Udmurt Federal Research Center, Ural Branch of the Russian Academy of Sciences

Email: Vasily_L.84@udman.ru
Russian Federation, Izhevsk

P. V. Bykov

Udmurt Federal Research Center, Ural Branch of the Russian Academy of Sciences

Email: Vasily_L.84@udman.ru
Russian Federation, Izhevsk

V. Ya. Bayankin

Udmurt Federal Research Center, Ural Branch of the Russian Academy of Sciences

Email: Vasily_L.84@udman.ru
Russian Federation, Izhevsk

A. L. Ulyanov

Udmurt Federal Research Center, Ural Branch of the Russian Academy of Sciences

Email: Vasily_L.84@udman.ru
Russian Federation, Izhevsk

References

  1. Bai H., Zhong L., Kang L., Liu J., Zhuang W., Lv Z., Xu Y. A review on wear-resistant coating with high hardness and high toughness on the surface of titanium alloy // J. Alloys Compounds. 2021. V. 882. P. 160645.
  2. Liu X., Chu P., Ding C. Surface modification of titanium, titanium alloys, and related materials for biomedical applications // Mater. Sci. Eng.: R: Reports. 2004. V. 47. P. 49–121.
  3. Li Y., Wang Z., Shao M., Zhang Z., Wang C., Yan J., Lu J., Zhang L., Xie B., He Y., Qiu J.X. Characterization and electrochemical behavior of a multilayer-structured Ti–N layer produced by plasma nitriding of electron beam melting TC4 alloy in Hank's solution // Vacuum. 2022. V. 208. P. 111737.
  4. Jiang X.J., Wang S.Z., Feng Z.H., Qi H.B., Fu H., Liu R.P. Improving vacuum gas nitriding of a Ti-based alloy via surface solid phase transformation // Vacuum. 2022. V. 197. P. 110860.
  5. Ахмадеев Ю.Х., Иванов Ю.Ф., Коваль Н.Н., Лопатин И.В., Щанин П.М. Азотирование титана ВТ1-0 в несамостоятельном тлеющем разряде низкого давления в различных газовых средах // Поверхность. Рентгеновские, синхротронные и нейтронные исследования. 2008. № 2. С. 108–112.
  6. Поболь И.Л., Олешук И.Г., Дробов А.Н., Фун С., Лиин В. Исследование формирования упрочненных слоев на титановых сплавах методом ионноплазменного азотирования // Вестник Национальной академии наук Белоруссии. Серия физико-технических наук. 2019. Т. 64. № 1. С. 25–34.
  7. Zhevtun I.G., Gordienko P.S., Yarusova S.B., Silant’ev V.E., Yudakov A.A. Producing a microporous structure on titanium alloys by means of plasma surface treatment // Protection Metals Phys. Chem. Surfaces. 2017. V. 53. P. 100–104.
  8. Tyunkov A.V., Golosov D.A., Zolotukhin D.B., Nikonenko A.V., Oks E.M., Yushkov Yu.G., Yakovlev E.V. Nitriding of titanium in electron beam excited plasma in medium vacuum // Surface Coatings Techn. 2020. V. 383. P. 125241.
  9. Ахмадеев Ю.Х., Гончаренко И.М., Иванов Ю.Ф., Коваль Н.Н., Щанин П.М. Азотирование технически чистого титана в тлеющем разряде с полым катодом // Письма в ЖТФ. 2005. Т. 31. № 13. С. 24–30.
  10. Vlcak P., Sepitka J., Drahokoupil J., Tomas Horazdovsky T., Tolde Z. Structural characterization and mechanical properties of a titanium nitride-based nanolayer prepared by nitrogen ion implantation on a titanium alloy // J. Nanomaterials. 2016. V. 5. P. 1–7.
  11. Vorobyev V.L., Bykov P.V., Bystrov S.G., Kolotov A.A., Bayankin V.Ya. The effect of the chemical activity of the implanted element to metal alloy components on the formation of surface layers under ion irradiation // Diagnostics, Resource Mechanics Mater. Structures. 2023. V. 3. P. 29–43.
  12. Александров Д.А., Мубояджян С.А., Луценко А.Н., Журавлева П.Л. Упрочнение поверхности титановых сплавов методом ионной имплантации и ионного модифицирования // Авиационные материалы и технологии. 2018. T. 2. C. 33–39.
  13. Шелехов E.В., Свиридова Т.А. Программы для рентгеновского анализа поликристаллов // Металловедение и термическая обработка металлов. 2000. № 8. C. 16–19.
  14. Поплавский В.В., Поболь И.Л., Дробов А.Н. Исследование процессов фазообразования при ионно-плазменном азотировании сплавов титана / Тезисы докладов 15-ой Международной конференции “Взаимодействие излучений с твердым телом”, Минск, Беларусь. 2023. C. 102–104.
  15. Дробов А.Н., Босяков М.Н., Поболь И.Л. Влияние ионно-плазменного азотирования на износостойкость и характер изменения шероховатости поверхности титановых сплавов ВТ1-0, ВТ6 и ОТ4-1 // Литье и металлургия. 2022. № 2. С. 78–83.
  16. Болгар А.С., Литвиенко В.Ф. Термодинамические свойства нитридов. Киев: Наукова Думка, 1980. С. 282.
  17. Воробьев В.Л., Быков П.В., Колотов А.А., Гильмутдинов Ф.З., Аверкиев И.К., Баянкин В.Я. Особенности формирования поверхностных слоев нержавеющей стали и титанового сплава имплантацией ионов N+ // ФММ. 2021. Т. 122. № 12. С. 1302–1308.

Supplementary files

Supplementary Files
Action
1. JATS XML
Download
2. Fig. 1. AFM images of the surface morphology of the studied samples: (a) – original sample; (b) – N+ plasma with heating of samples to 300°C; (c) – N+ plasma with heating of samples to 500°C; (d) – N+ plasma with heating of samples to 700°C.

Download (604KB)
Indexing metadata
3. Fig. 2. Distribution profiles of elements in samples of titanium alloy VT6 in the initial state (a) and after treatment in nitrogen plasma without heating (b).

Download (68KB)
Indexing metadata
4. Fig. 3. Distribution profiles of elements in titanium alloy VT6 after treatment in N+ ion plasma with heating of samples to 300°C (a); 500°C (b); 700°C (c).

Download (111KB)
Indexing metadata
5. Fig. 4. Distribution profiles of nitrogen (a) and oxygen (b) in VT6 samples treated in N+ ion plasma under different conditions: initial sample (1), N+ ion plasma without heating the samples (2) and with heating to temperatures of 300°C (3); 500°C (4); 700°C (5).

Download (71KB)
Indexing metadata
6. Fig. 5. O1s XPS spectrum obtained from a depth of ~20 nm in sample BT6 after plasma treatment without heating (a); with heating at 300°C (b); 500°C (c); 700°C (d).

Download (96KB)
Indexing metadata
7. Fig. 6. N1s XPS spectrum obtained from a depth of ~20 nm in sample BT6 after plasma treatment without heating (a); with heating at 300°C (b); 500°C (c); 700°C (d).

Download (71KB)
Indexing metadata
8. Fig. 7. XPS spectra of Ti2p of VT6 samples obtained from a depth of ~20 nm in the initial state (1); after plasma treatment without heating (2); with heating of samples to 300°C (3); 500°C (4); 700°C (5).

Download (77KB)
Indexing metadata
9. Fig. 8. Diffraction patterns of VT6 titanium alloy samples in the initial state (1); after treatment in N+ ion plasma without heating (2), and with heating of samples to temperatures of 300°C (3), 500°C (4), 700°C (5).

Download (36KB)
Indexing metadata
10. Fig. 9. Relative change in microhardness of VT6 titanium alloy samples as a result of treatment in N+ ion plasma without heating (2); with heating of samples to temperatures of 300°C (3), 500°C (4), 700°C (5).
