On the Theory of the Method of “Echoscopy” of the Bottomhole Zon e of a Well in a Low-Permeability Formation Subject to Hydraulic Fracturing

R. A. Bashmakov; Башмаков Р. А.; E. V. Galiakbarova; Галиакбарова Э. В.; Z. R. Khakimova; Хакимова З. Р.; V. Sh. Shagapov; Шагапов В. Ш.

doi:10.31857/S0032823523020042

On the Theory of the Method of “Echoscopy” of the Bottomhole Zon e of a Well in a Low-Permeability Formation Subject to Hydraulic Fracturing

Authors: Bashmakov R.A.¹^,2, Galiakbarova E.V.¹^,3, Khakimova Z.R.¹^,3, Shagapov V.S.¹
Affiliations:
1. Mavlutov Institute of Mechanics
2. Ufa University of Science and Technology
3. Ufa State Petroleum Technological University
Issue: Vol 87, No 2 (2023)
Pages: 314-326
Section: Articles
URL: https://rjonco.com/0032-8235/article/view/675168
DOI: https://doi.org/10.31857/S0032823523020042
EDN: https://elibrary.ru/TZACKT
ID: 675168

Cite item

Full Text

Open Access
Restricted Access

Access granted
Restricted Access

Subscription or Fee Access

Abstract

We build a mathematical model describing the evolution of the pulse signal in the well in the presence of a longitudinal or transverse fracture in the bottomhole section. It is assumed that the signal is sent from the wellhead with a wavelength greater than the diameter of the well and the length of the open section of the well. According to the dynamics of the “echo” of the pulse signal returning to the wellhead, it is possible to judge the quality of hydraulic fracturing. The results of numerical calculations for a bell-shaped pulse are presented. It is shown that when diagnosing fractures, water is more preferable than oil as a fluid through which the signal propagates.

Keywords

pulse signal, hydraulic fracturing, oil well, wave phase, reflection coefficient, harmonic waves

References

Kremenetskiy M.I., Ipatov A.I. Hydrodynamic and Field-Technological Studies of Wells. Moscow: MAKS Press, 2008.
Economides M.J., Ronald E.O., Valko P. Unified Fracture Design Bridging the Gap between Theory and Practice. Alvin, TX: Orsa Press, 2002. 200 p.
Baikov V.A., Bulgakova G.T., Il’yasov A.M., Kashapov D.V. Estimation of the geometric parameters of a reservoir hydraulic fracture // Fluid Dyn., 2018, vol. 53, pp. 642–653. http://ras.jes.su/mzg/s207987840000962-7-2-en.
Bashmakov R.A., Nasyrova D.A., Shagapov V.Sh. Natural vibrations of a fluid in a well connected with formation in the presence of a hydraulic fracture // Fluid Dyn., 2021, vol. 56, pp. 1049–1061. https://doi.org/10.1134/S0015462821080024
Holzhausen G.R., Gooch R.P. Impedance of hydraulic fractures: its measurement and use for estimating fracture closure pressure and dimensions // SPE/DOE Low Permeability Gas Reservoirs Symp., Denver / Colorado, May 1985. Paper No: SPE- SPE-13892-MS.
Wang X., Hovem K., Moos D., Quan Y. Water Hammer effects on water injection well performance and longevity // SPE Int. Symp. & Exhib. on Formation Damage Control, 2008, SPE-112282-MS. doi: https://doi.org/10.2118/112282-MS
Shagapov V.S., Galiakbarova E.V., Khakimova Z.R. On the theory of local sounding of hydraulic fractures using pulsed pressure waves // J. Appl. Mech. Tech. Phys., 2021, vol. 62, pp. 563–572. https://doi.org/10.1134/S0021894421040052
Galiakbarova E.V. The influence of the conductivity of a hydraulic fracturing crack on the possibility of diagnosing using an acoustic “TV” // Bull. Bashk. Univ., 2021, vol. 26, no. 4, pp. 866–870. doi: https://doi.org/10.33184/bulletin-bsu-2021.4.2
Shagapov V.S., Nagaeva Z.M., Anosova E.P. Elastic filtration of fluid to a wellbore through a fracture perpendicular to it and formed during hydraulic fracturing // J Appl. Mech. Tech. Phys., 2022, vol. 63, pp. 643–651. https://doi.org/10.1134/S0021894422040113
Nagaeva Z.M., Shagapov V.Sh. Elastic seepage in a fracture located in an oil or gas reservoir // JAMM, 2017, vol. 81, iss. 3, pp. 214–222.
Lyons R.G. Understanding Digital Signal Processing. Upper Saddle River, NJ: Prentice Hall PTR, 2001. xvii+517 p.
Landau L.D., Lifshits E.M. Theoretical Physics. Vol. 6: Hydrodynamics. Moscow: Nauka, 1986.
Ifeachor E.C., Jervis B.W. Digital Signal Processing. Addison-Wesley Publ. Company, 1993. xxiii+760p.
