Consolidation of al and Ta-substituted Li7La3Zr2O12 powders with lithium-ion conductivity by spark plasma sintering

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription Access

Abstract

Monophase powders of cubic modification with nominal composition Li6.4Al0.2La3Zr2O12 (Al–LLZ) and Li6.52Al0.08La3Zr1.75Ta0.25O12 (Ta–LLZ) were synthesized. Dense (~97–98%) ceramic samples of solid electrolyte with increased stability in air were obtained from these powders by spark plasma sintering. High Li-ion conductivity (4–6×10–4 S/cm) corresponding to the world level have been achieved.
